MEGApix® 5MP vandal dome Snapit IP camera with 2.7~13.5mm vari-focal p-iris lens, motorized zoom and auto-focus, color in near-total darkness and IR

Share this Product!

Vandal dome Snapit IP camera with 2.7~13.5mm vari-focal p-iris lens, motorized zoom and auto-focus, color in near-total darkness and IR

Model: DWC-MV45WiATW

Find a Reseller | Request a Demo | Contact Us

This MEGApix^® IP camera is NDAA/TAA compliant and provides 5MP resolution at real-time 30fps. It includes simultaneous H.265/H.264/MJPEG codec support, Star-Light Plus™ color in near-total darkness technology for quality video in any lighting condition and Cold Start at -40° F/-40° C. The unique Snapit™ housing is easy to install, includes CleanView™ dome treatment and is IP68-rated. All MEGApix cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Cold Start -40°F (-40°C)

The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.

Snapit™ Outdoor Vandal Dome Housing

Our Snapit™ housing offers a simple to install, three-step process. All Snapit™ outdoor dome models are IP68 and IK10 rated, include DW®’s CleanView™ hydrophobic dome coating to repel water, dust and grease and will Cold Start at -40°F./-40°C.

H.265 codec support

High-Efficiency video codec standards deliver 25% to 50% better data compression while maintaining video quality.

5MP 1/2.8" image sensor at real-time 30fps
Star-Light Plus™ color in near-total darkness technology
2.7~13.5mm vari-focal p-iris lens with motorized zoom and auto-focus
True Wide Dynamic Range (WDR)
Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
100' Smart IR™ with intelligent camera sync
CleanView™ hydrophobic dome coating repels water, dust and grease
Snapit™ easy installation camera
Smart DNR™ 3D digital noise reduction
True day/night with mechanical IR cut filter
Programmable privacy zones
Auto gain control (AGC)
Auto white balance (AWB)
Motion detection
Two-way audio
Micro SD/SDHC/SDXC class 10 card slot (card not included)
Alarm sensor input
Relay output
Web server built-in
PoE class 3 and DC12V
UL listed
ONVIF conformant, profile S
NDAA/TAA compliant
IP68 dust-tight and waterproof
IK 10-rated impact-resistant
5 year warranty

Image sensor	5MP 1/2.8” CMOS
Total pixels	2592 (H) × 1944 (V)
Minimum scene illumination	0.08 lux (color)
Minimum scene illumination	0.0 lux (B/W)
Video output	Local video output CVBS 1.0V p-p (75?), 4:3 aspect ratio
LENS
Focal length	2.7 ~ 13.5mm, F1.4
Lens type	Vari-focal p-iris lens with motorized-zoom and auto-focus
Field of view (FoV)	31° ~ 96°
IR distance	100ft range
Optical zoom	x5 optical zoom
I/O
Audio in / out	1/1
Audio compression	G.711
Alarm in / out	1/1
OPERATIONAL
Shutter mode	Auto, manual, anti-flicker, slow shutter
Shutter speed	1/15 ~ 1/32,000
Slow shutter	1/2,1/3,1/5,1/6,1/7.5, 1/10
Auto gain control	Auto
Day / night	Auto, day (color), night (B/W)
Smart DNR™ 3D digital noise reduction	3D DNR
Wide dynamic range (WDR)	True WDR (T-WDR)
Wide dynamic range (WDR) dB	120dB
Privacy zones	16 programmable privacy masks
Mirror and flip	Yes
Alarm notifications	Notifications via e-mail, FTP, alarm output activation and SD card recording
Memory slot	Micro SD / SDHC / SDXC (card not included)
NETWORK
LAN	RJ45 (10/100Base-T)
Video compression type	H.265, H.264, MJPEG
Resolution	H.265: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: 2592x1944, 2304x1296, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF
Frame rate	Up to 30fps at all resolutions
Video bitrate	100Kbps ~ 10Mbps, Multi-rate for Preview and Recording
Bitrate control	Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
Streaming capability	Dual-stream at different rates and resolutions
IP	IPv4, IPv6
Protocol	TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
Security	HTTPS(TLS), IP filtering, 802.1x, digest authentication (ID/PW)
ONVIF conformance	Yes
Web viewer	OS: Windows®, Mac® OS, Linux® Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari®
Video management software	DW Spectrum® IPVMS
ENVIRONMENTAL
Operating temperature	-40°F ~ 122°F (-40°C ~ 50°C)
Operating humidity	10–90% RH (non–condensing)
IP rating	IP68-rated
IK rating	IK10 impact-resistant
Other certifications	CE, FCC, RoHS
ELECTRICAL
Power requirement	DC12V, POE IEEE 802.3af class 3 (adaptor not Included)
Power consumption	DC12V: max 8.3W PoE: max 10.5W
MECHANICAL
Material	Snapit™ aluminum vandal housing, polycarbonate dome
Dimensions	5.47" x 4.93" (139 x 125.4mm)
Weight	2.75 lbs (1.25kg)
Warranty	5 year warranty

DW Spectrum® IPVMS

LEARN MORE

Blackjack® servers

LEARN MORE

C3™ CMS

LEARN MORE

VMAX® IP Plus™ NVRs

LEARN MORE

DWC-V4CMW

Ceiling mount bracket - white

DWC-V1CNMW

Corner and pole mount bracket - white

DWC-V4WMW

Wall mount bracket - white

Title	Type	Size	Download
DW Accessories Chart		0.06 MB
DWC-M(P)V45WiATW series quick setup guide		2.50 MB
DWC-MV45WiATW CAD drawing		0.17 MB
DWC-MV45WiATW datasheet		0.76 MB
DWC-MV45WiATW UL certificate		5.09 MB
DWC-MV45_MPV45 series user manual		5.49 MB
MEGApix Single-Sensor Brochure		7.25 MB
