MEGApix® 4K low-profile vandal dome IP camera with 3.6~10mm vari-focal p-iris lens with motorized zoom and auto-focus and color in near-total darkness

Share this Product!

MEGApix® 4K low-profile vandal dome IP camera with 3.6~10mm vari-focal p-iris lens with motorized zoom and auto-focus and color in near-total darkness

Model: DWC-MVC8WiATW

Find a Reseller | Request a Demo | Contact Us

This MEGApix^® IP camera provides 4K resolution at real-time 30fps. It includes a 3.6~10mm vari-focal auto-focus lens with motorized zoom, simultaneous H.265/H.264/MJPEG codec support and Star-Light Plus™ color in near-total darkness technology for quality video in any lighting condition. The IP66-rated, IK-10 impact-resistant vandal housing features CleanView™ self-cleaning dome treatment. All MEGApix^® cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

True Wide Dynamic Range (WDR)

Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.

CleanView™ Hydrophobic Dome Coating

The CleanView™ coating improves visibility by reducing water spots, dust and grease build-up on the camera dome housing’s glass. The CleanView™ coating treatment will allow the liquid to roll off of the dome’s glass surfaces when tilted vertically up to 10° or less. The CleanView™ coating leaves the camera dome’s glass clean, repels dust and grease, preventing IR reflections due to dust and smudges.

4K 1/1.8" image sensor at real-time 30fps
Star-Light Plus™ color in near-total darkness technology
3.6~10mm vari-focal p-iris lens with motorized zoom and auto-focus
True Wide Dynamic Range (WDR)
Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
100' Smart IR™ with intelligent camera sync
CleanView™ hydrophobic dome coating repels water, dust and grease
Smart DNR™ 3D digital noise reduction
True day/night with mechanical IR cut filter
Programmable privacy zones
Auto gain control (AGC)
Backlight compensation (BLC)
Auto white balance (AWB)
Motion detection
Two-way audio
Micro SD/SDHC/SDXC class 10 card slot (card not included)
Alarm sensor input
Relay output
Web server built-in
PoE class 3 and DC12V
ONVIF conformant, profile S
NDAA/TAA compliant
IP66 environmental-rated dust-tight and water-resistant
IK 10-rated impact-resistant
5 year warranty

Image sensor	4K 1/1.8” CMOS
Total pixels	3952 (H) × 2320 (V)
Minimum scene illumination	0.09 lux (color)
Minimum scene illumination	0.0 lux (B/W)
Video output	Local video output CVBS 1.0V p-p (75?), 4:3 aspect ratio
LENS
Focal length	3.6~10mm, F1.5
Lens type	Vari-focal p-iris lens with motorized-zoom and auto-focus
Field of view (FoV)	98.4° ~ 45.7°
IR distance	100ft range
Optical zoom	x2.7 optical zoom
I/O
Audio input/output	1/1
Audio compression	G.711
Alarm input/output	1/1
OPERATIONAL
Shutter mode	Auto, manual, anti-flicker, slow shutter
Shutter speed	1/15 ~ 1/32,000
Slow shutter	1/2,1/3,1/5,1/6,1/7.5, 1/10
Auto gain control	Auto
Day / night	Auto, day (color), night (B/W)
Smart DNR™ 3D digital noise reduction	3D DNR
Wide dynamic range (WDR)	True WDR (max. 15fps when WDR is on) On, Off
Wide dynamic range (WDR) dB	120dB
Privacy zones	16 programmable privacy masks
Backlight compensation (BLC)	Yes
Mirror and flip	Yes
Alarm notifications	Notifications via e-mail notifications, FTP, alarm output and SD card recording
Memory slot	Micro SD / SDHC / SDXC (card not included)
NETWORK
LAN	1000Base-T (1Gbps)
Video compression type	H.265, H.264, MJPEG
Resolution	H.265: QFHD/1080p/720p/VGA/D1/CIF H.264: QFHD/1080p/720p/VGA/D1/CIF MJPEG: 1080p/720p/800x600/VGA/768x432/D1/CIF
Frame rate	Up to 30fps at all resolutions
Video bitrate	100Kbps ~ 10Mbps, multi-rate for preview and recording
Bitrate control	Multistreaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
Streaming capability	Dual-stream at different rates and resolutions
IP	IPv4, IPv6
Protocol	TCP/IP, UDP, AutoIP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB-2), ONVIF
Security	HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW)
ONVIF conformance	Yes
Web viewer	OS: Windows^®, Mac^® OS, Linux^® Browser: Internet Explorer^®, Google Chrome^®, Mozilla Firefox^®, Safari^®
Video management software	DW Spectrum^® IPVMS
ENVIRONMENTAL
Operating temperature	-4°F ~ 122°F (-20°C ~ 50°C)
Operating humidity	10–90% RH (non–condensing)
IK rating	IK10 impact-resistant
IP rating	IP66-rated
Other certifications	CE, FCC
ELECTRICAL
Power requirement	DC 12V, PoE IEEE (802.3af class 3). (Adapter not included)
Power consumption	DC12V: max 9.3W PoE: max 11.6W
MECHANICAL
Material	Aluminum vandal housing, polycarbonate dome
Dimensions	4.9" x 3.6" (125 x 92 mm)
Weight	1.14 lb (0.51kg)
Warranty	5 year warranty
