IMAGE |
||
Image sensor |
2.1MP/1080p 1/2.7” CMOS |
|
Active pixels |
1944 (H) x 1092 (V) |
|
Scanning system |
Progressive scan |
|
Frequency |
60Hz / 50Hz | |
Signal technology |
Universal HD over Coax® technology with HD-Analog, HD-TVI, HD-CVI and all analog to 960H signal support | |
Synchronization |
Internal | |
Resolution |
1920 x 1080 (1080p) | |
Minimum scene illumination |
0.2 lux (color) |
|
0 lux (B&W) |
||
S/N ratio |
55dB | |
Video output |
HD-Analog, HD-TVI, HD-CVI 2.1MP/1080p CVBS Analog up to 960H | |
LENS |
||
Focal length |
2.8 ~ 12mm | |
Lens type |
Varifocal p-iris lens | |
Field of view (FoV) |
95.5 - 30.8° |
|
IR distance |
100ft range |
|
OPERATIONAL |
||
Shutter mode |
Auto, manual |
|
Shutter speed |
1/30-1/30,000 |
|
Backlight |
On, off |
|
Star-Light (sense-up) |
Off, x2 – x30 |
|
Dynamic range compressor (DRC) |
Off, on, auto |
|
Smart DNR™ 3D digital noise reduction |
Off, low, middle, high |
|
White balance |
Auto / push / ATW / manual |
|
Day / night |
Auto, day (color), night (B/W)
|
|
Mirror / flip |
Yes |
|
Auto gain control |
0~15 |
|
Motion detection |
Yes |
|
Privacy zones |
4 programmable privacy zones |
|
Sharpness |
On, off |
|
Gamma |
0.45 ~ 0.75 |
|
De-fog |
On, off |
|
ENVIRONMENTAL |
||
Operating temperature |
-4°F ~ 122°F (-20°C ~ 50°C)
|
|
Operating humidity |
10–90% RH (non–condensing)
|
|
IP rating |
IP66 certified weather and tamper resistant
|
|
IK rating |
IK10-rated impact resistant
|
|
Other certifications |
FCC, CE, ROHS
|
|
ELECTRICAL |
||
Power requirement |
DC12V
|
|
Power consumption |
DC12V (LED OFF): 1.86W
|
|
DC12V (LED ON): 3.6W
|
||
MECHANICAL |
||
Material |
Aluminum vandal housing, polycarbonate dome
|
|
Dimensions |
5.7" x 4.26" (145 x 108.3 mm)
|
|
Weight |
1.65lbs (0.75kg) |
|
